Overview

Following Previous Post: #5, this is the 6th cycle. The big move: GPU inference (rembg + SAM2) leaves the backend and lives on a dedicated RunPod Serverless worker. Backend becomes a thin orchestrator. On the product side, custom motion prompts and frame-candidate swap let users iterate on individual frames without re-running the whole pipeline.

Architecture Shift

graph TD
    A[Old: monolithic backend] --> B[Backend <br/> rembg + SAM2 in-process]
    C[New: split deployment] --> D[Backend orchestrator]
    C --> E[gpu_worker <br/> RunPod Serverless]
    D -->|asyncio.gather| E
    E --> F[rembg_service]
    E --> G[sam_service]
    E --> H[birefnet_service]

GPU Worker on RunPod Serverless

Background

The backend was holding rembg and SAM2 model weights in process. That made each backend instance a 4GB+ memory hog and forced the backend onto GPU machines just to serve API traffic. The fix: extract inference to a Serverless worker so the backend can run on cheap CPU instances.

Implementation

A new gpu_worker/ directory:

• Dockerfile — bakes model weights into the image to avoid network-volume cold-start penalty
• handler.py — RunPod handler signature, dispatches to one of three services
• services/rembg_service.py, sam_service.py, birefnet_service.py — pure inference functions
• requirements.txt — pinned torch/torchvision/onnxruntime versions

The handler accepts { "task": "rembg" | "sam" | "birefnet", "image": "<base64>", "params": {...} } and returns alpha mask base64.

Backend Refactor

backend/gpu_client.py is the new HTTP client to the RunPod endpoint. The old in-process inference paths in processor.py and sam_segmenter.py are replaced with await gpu_client.infer(...) calls.

Async Parallelization

Per-frame inference was sequential — a 30-frame animation took 30 × per-frame latency. Refactor to fire N RunPod requests in parallel via asyncio.gather:

results = await asyncio.gather(*[
    gpu_client.infer({"task": "rembg", "image": frame})
    for frame in frames
])

The bottleneck shifted from compute to RunPod’s autoscaler — when 30 requests land at once, the cold-start of additional Flex workers caps wall-clock latency at ~the slowest cold start, not 30× the warm latency.

Custom Motion Prompts + Frame Swap

Product feature, not infra. Users can now type a custom motion description (“subtle bounce”, “slow zoom”) that gets injected into the animation prompt template, and swap individual frame candidates from the refine UI. Concretely:

• Backend stores per-frame candidates from the generation step
• Frontend EmojiPreview.tsx and RembgRefineCanvas.tsx let users pick which candidate to keep per frame
• A retry endpoint regenerates a single frame with the user’s modified prompt

Commit Log

Insights

The Serverless extraction pays for itself the moment per-frame latency starts mattering. With the inference inline in the backend, you couldn’t parallelize without spinning up multiple backend processes — and those processes each loaded a 4GB model. With Serverless workers, parallelism is just asyncio.gather and RunPod handles the worker pool. The pattern — keep the orchestrator small and stateless on cheap CPU, push the GPU work to a queue-based handler — is the right shape for any AI product where the inference is bursty. The custom motion prompts feature, while a smaller change, is worth more in user value per line of code than the entire infrastructure refactor. Both shipped in the same cycle, which is the goal.
